172 mm x 172 mm x 51 mm Tube Axial Fan 12 VDC Ball Bearing 318CFM 60.1dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$85.950

In Stock: 0

Quantity	Unit Price	You Save	Discount
200+	$85.950	-	-
400+	$81.650	4.30	5%

Features

Voltage Rating: 12 VDC
Height: 172 mm
Width: 172 mm
Depth: 51 mm
Air Flow (CFM): 318
Bearing: Ball
Current Rating: 5400 mA
Power Rating: 64.8 W
Agency Approvals: UL, CUL, TUV, CE, UKCA
Noise (dBA): 60.1
Termination: 12" Wires
Product Type: 172mm x 172mm DC Fan
Speed: 4125 rpm
Maximum Pressure: 1.05 in.
Additional Features: Die Cast Aluminum Frame Black, PBT Impeller
Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 4125 rpm.
