172 mm x 172 mm x 51 mm Tube Axial Fan 12 VDC Ball Bearing 230CFM 52.7dBA 12" Wires

Features

  • Voltage Rating: 12 VDC
  • Height: 172 mm
  • Width: 172 mm
  • Depth: 51 mm
  • Air Flow (CFM): 230
  • Bearing: Ball
  • Current Rating: 1900 mA
  • Power Rating: 22.8 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 52.7
  • Termination: 12" Wires
  • Product Type: 172mm x 172mm DC Fan
  • Speed: 3250 rpm
  • Maximum Pressure: 0.78 in.
  • Additional Features: Die Cast Aluminum Frame Black, PBT Impeller
  • Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3250 rpm.

Product Identification

Additional Feature:Die Cast Aluminum Frame Black, PBT Impeller
Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:51 mm
Height:172 mm
Width:172 mm

Features

Bearing:Ball
Motor Drive Type:Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected
Air Flow (CFM):230
Voltage Rating:12 VDC
Maximum Pressure:0.78 in.
Speed:3250 rpm
Termination:12" Wires
Noise (dBA):52.7
Power Rating:22.8 W
Current Rating:1900 mA
,
