172 mm x 150 mm x 51 mm Tube Axial Fan 115 VAC Dual Ball Bearing 141CFM 52dBA Terminals

Features

  • Voltage Rating: 115 VAC
  • Height: 150 mm
  • Width: 172 mm
  • Depth: 51 mm
  • Air Flow (CFM): 141
  • Bearing: Dual Ball
  • Current Rating: 300 mA
  • Power Rating: 35 W
  • Agency Approvals: UL, CUL, TUV
  • Noise (dBA): 52
  • Termination: Terminals
  • Product Type: Louvered Filter Fan Kit with Fan Installed
  • Speed: 3200 rpm
  • IP Rating: IP54
  • Maximum Pressure: 0.70 in.
  • Additional Features: Die Cast Aluminum Frame Black, PBT Impeller, Louvered Filter Kit, Class B Insulation, Hinged Guard
  • Motor Drive Type: Capacitor Drive, Impedance Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Dual Ball bearing system of the tube axial fan is designed to operate up to 3200 rpm.

,
