172 mm x 150 mm x 51 mm Tube Axial Fan 24 VDC Ball Bearing 323CFM 63.5dBA 12" Wires

Features

  • Voltage Rating: 24 VDC
  • Height: 150 mm
  • Width: 172 mm
  • Depth: 51 mm
  • Air Flow (CFM): 323
  • Bearing: Ball
  • Current Rating: 2100 mA
  • Power Rating: 50.4 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 63.5
  • Termination: 12" Wires
  • Product Type: 172mm x 150mm DC Fan
  • Speed: 4400 rpm
  • IP Rating: IP69K
  • Maximum Pressure: 1.06 in.
  • Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 4400 rpm.

Product Identification

Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:51 mm
Height:150 mm
Width:172 mm

Features

Bearing:Ball
Motor Drive Type:Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected
IP Rating:IP69K
Voltage Rating:24 VDC
Maximum Pressure:1.06 in.
Speed:4400 rpm
Termination:12" Wires
Noise (dBA):63.5
Air Flow (CFM):323
Power Rating:50.4 W
Current Rating:2100 mA
,
