172 mm x 150 mm x 51 mm Tube Axial Fan 24 VDC Ball Bearing 180CFM 42dBA 12" Wires

Features

  • Voltage Rating: 24 VDC
  • Height: 150 mm
  • Width: 172 mm
  • Depth: 51 mm
  • Air Flow (CFM): 180
  • Bearing: Ball
  • Current Rating: 520 mA
  • Power Rating: 12.48 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 42
  • Termination: 12" Wires
  • Product Type: 172mm x 150mm DC Fan
  • Speed: 2500 rpm
  • IP Rating: IP68
  • Maximum Pressure: 0.51 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 2500 rpm.

Product Identification

Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:51 mm
Height:150 mm
Width:172 mm

Features

Bearing:Ball
Noise (dBA):42
Speed:2500 rpm
Motor Drive Type:Brushless DC, Auto Restart, Polarity Protected, Electronically Protected
Maximum Pressure:0.51 in.
IP Rating:IP68
Voltage Rating:24 VDC
Termination:12" Wires
Air Flow (CFM):180
Power Rating:12.48 W
Current Rating:520 mA
,
