172 mm x 150 mm x 38.5 mm Tube Axial Fan 24 VDC Ball Bearing 224.2CFM 55.3dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$85.650

In Stock: 0

Quantity	Unit Price	You Save	Discount
1+	$85.650	-	-
5+	$78.750	6.90	8.06%
25+	$72.450	13.20	15.41%

Features

Voltage Rating: 24 VDC
Height: 150 mm
Width: 172 mm
Depth: 38.5 mm
Air Flow (CFM): 224.2
Bearing: Ball
Current Rating: 970 mA
Power Rating: 23.28 W
Agency Approvals: UL, CUL, TUV, CE, UKCA
Noise (dBA): 55.3
Termination: 12" Wires
Product Type: 172mm x 150mm DC Fan
Speed: 3950 rpm
Maximum Pressure: 0.73 in.
Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3950 rpm.
