16.5W Single Output DC-DC Converter


Output: 3.3 Volts @ 5 Amps

Features:
  • Input voltage range: 18-36VDC
  • Built-in remote on-off control
  • Cooling by free air convection
  • 100% full load burn-in test
  • 1000VDC I/O isolation
  • Fixed switching frequency at 225kHz
  • Protections: Short-circuit, overload, over-voltage
  • Efficiency: 79%
  • Compact size: 2.0"L x 2.0"W x 0.63"H
  • Weight: 3.5 oz. (100 grams)
  • 1-year warranty

    • Product Identification

    Type:Step Down
    Product Type:DC-DC Single Output Converter SMPS
    Manufacturer Series:SDM30

    Dimensions & Appearance

    Height:0.63 in.
    Width:2 in.
    Length:2 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:85°C

    Input

    Input Voltage:24 VDC
    Input Voltage Range:24 VDC

    Output

    Number of Outputs:1
    Output Voltage:3.3 VDC
    Additional Output Voltages (VDC):N/A
    Output Current:5 A

    Features

    Pins:6
    Power Rating:16.5 W
    ,
