160W 30V 3 Channel High Performance Linear DC Power Supply (DP831)

Features

  • Channels: 3
  • CH1: 8V/5A; CH2: 30V/2A; CH3: -30V/2A
  • Total Power: 160 Watts
  • Max Voltage: 30 Volts
  • Max Current: 5 Amps
  • Low Ripple and Noise: <350 uVrms/2mVpp
  • Fast Transient Response Time: < 50us
  • 3.5 Inch TFT Display

Overview

Powerful platform that combines the ability to source, analyze, and coordinate across time with the Linear DC Power Supply with 3 output and 160 Watts overall.

Downloads & Resources

Product Identification

Product Type:Benchtop Power Supply
Manufacturer Series:ValuePro

Compliance

RoHS Status:ROHS Compliant

Dimensions & Appearance

Weight:21.5 lbs.
Depth:16.50 in.
Height:6.18 in.
Width:9.41 in.

Input

Input Frequency:50Hz, 60Hz
Input Voltage:100 VAC, 115VAC, 220 VAC

Output

Output Voltage:0 VDC to 8 VDC, 0 VDC to 30 VDC, 0 VDC to -30 VDC
Number of Outputs:3
Output Current:0 A to 5 A, 0 A to 2 A, 0 A to 2 A
Output Connector Type:Banana Jacks

Features

Type of Displays:Digital LCD
Power Rating:160 W
,
