15W Regulated Dual Output DC-DC Converter


Output: ±15 Volts @ 0.5 Amps


Features:

  • Input voltage range: 18-72VDC
  • Rated DC input: 48V
  • Efficiency: 84%
  • Wide 4:1 DC input range
  • Protections: Short circuit / Overload / Over voltage
  • 1500VDC I/O isolation
  • Built-in EMI filter
  • Cooling by free air convection
  • Output voltage trimming function
  • Built-in remote ON-OFF control
  • 100% full load burn-in test
  • Size: 1.5"L x 2.0"W x 0.39"H
  • Weight: 0.066 lbs.

    • Product Identification

    Product Type:DC-DC Regulated Single Output Power Supply SMPS
    Manufacturer Series:NSD15

    Compliance

    Agency Approvals: CE, CUL, EAC, EN, UL, UL, CUL, CE, EN, EAC

    Dimensions & Appearance

    Color:Black
    Height:0.387 in.
    Width:1.5 in.
    Length:2 in.
    Mounting:Through Hole

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:70°C

    Input

    Input Voltage Range:18 VDC to 72 VDC
    Input Voltage:48 VDC
    Maximum Input Current:0.4 A

    Output

    Number of Outputs:2
    Additional Output Voltages (VDC):-15 VDC
    Output Connector Type:PC Pins
    Output Voltage:15 VDC
    Output Current:0.50 A

    Features

    Pins:7
    Efficiency:84%
    Power Rating:15 W
    ,
