15W Encapsulated Dual Output DC-to-DC Converter

Output: ±5 Volts @ 1.5 Amps

Features:

  • Input range: 18-36VDC
  • Number of pins: 5
  • Line Regulation: ±0.2%
  • Load Regulation: ±0.5%
  • Ripple and Noise: 50mVp-p
  • Short-circuit/overload protection
  • 1000VDC I/O isolation
  • Shield metal case
  • Cooling by free air convection
  • Size: 2.0"L x 1.0"W x 0.44"H

    • Product Identification

    Type:Step Down
    Manufacturer Series:DKA15
    Product Type:DC-DC Dual Output Converter SMPS

    Compliance

    Agency Approvals: EAC, EN, FCC, UKCA, CE, CE, FCC, EN, EAC, UKCA

    Dimensions & Appearance

    Color:Black
    Height:0.40 in.
    Width:1 in.
    Length:2 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:71°C

    Input

    Input Voltage:24 VDC
    Input Voltage Range:18 VDC to 36 VDC
    Maximum Input Current:0.8 A

    Output

    Number of Outputs:2
    Additional Output Voltages (VDC):-5 VDC
    Output Voltage:5 VDC
    Output Connector Type:DIP
    Output Current:1.50 A

    Features

    Pins:5
    Power Rating:15 W
    ,
