15W DIN Rail Type DC-DC Converter 9-36VDC Input 5V 3A Output

Features

  • Width only 17.5mm (1SU)
  • -40 to 85°C
  • 4:1 wide input range
  • DC output adjustable(±10%)
  • 4000 VDC I/O isolation
  • Can be installed on DIN rail TS-35/7.5 or 15
  • Cooling by free air convection
  • Protections: Short circuit/Overload/Over voltage/Input reverse polarity/Input under voltage protection
  • No minimum load required
  • 3 year warranty

Applications

  • Telecom or Datacom system
  • Factory automation
  • Electro-mechanical
  • Wireless network
  • Semi-conductor fabrication equipment
  • Industrial control system

Product Identification

Product Type:DC-DC Converter SMPS
Manufacturer Series:DDR-15

Compliance

Agency Approvals:CE

Dimensions & Appearance

Mounting:DIN Rail
Color:Carbon
Width:0.688 in.
Height:2.30 in.
Length:3.54 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Input

Input Voltage Range:9 VDC to 36 VDC
Input Voltage:24 VDC
Maximum Input Current:2.4 A

Output

Number of Outputs:1
Output Voltage (Channel 1):5 VDC
Output Voltage:5 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):3 A
Output Current:3 A

Features

Minimum Isolation Voltage:400VDC
Switching Regulator:None
Pins:4
Efficiency:85%
Power Rating:15 W
,
