150W 24V 6.5A Enclosed Switchable AC-to-DC Power Supply
24 Volts DC @ 6.5 AmpsFeatures
- AC input voltage: 85-132 VAC / 176-264 VAC (switch selectable)
- Protections: Short circuit / Over load / Over voltage
- Cooling by free air convection
- LED indicator for power on
- 100% full load burn-in test
- All using 105°C long life electrolytic capacitors
- Withstands 300 VAC surge input for 5 seconds
- High operating temperature up to 70°C
- Withstands 5G vibration tests
- High efficiency, long life, and high reliability
- 3 year warranty
Product Identification
Type:Switch Selectable SMPS
Manufacturer Series:RS-150
Compliance
Agency Approvals: CB, CCC, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Height:1.5 in.
Width:3.9 in.
Length:7.8 in.
Operating conditions
Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:88 VAC to 132 VAC, 176 VAC to 264 VAC
Maximum Input Current:3 A
Output
Number of Outputs:1
Output Voltage (Channel 1):24 VDC
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Output Current (Channel 1):6.5 A
Output Current:6.50 A
Features
PFC Function:No
Minimum Isolation Voltage:3000V
Efficiency:86%
Power Rating:156 W
