150:1 Micro Metal Gearmotor 12mmDx24.2mmL 12V High-Power Carbon Brushes

For their size, these compact brushed DC gearmotors can generate a lot of power. A 12V brushed DC motor with long-life carbon brushes is paired with a 150:1 metal spur gearbox in this variant. The gearmotor has a diameter of 20 mm, and the D-shaped output shaft has a diameter of 4 mm and extends 18 mm from the gearbox face plate.

Specifications

• Rated Voltage: 12 VDC
• Brush Type: High-Power Carbon
• Stall Current: 0.75 A
• No Load Current: 80 mA
• No Load Speed: 220 rpm
• Stall Torque (extrapolated): 1.8 kg-cm (25 oz-in)
• Max Power: 1 W
• Gear Ratio: 150:1
• Size: 10x24mm diameter body + gearbox
• 4mm D-shaft (2.5mm to flat) (10 mm L)
