1/4" Flat Tinned Copper Wire Braid - 50 feet

Features

  • Consolidated Electronic Wire & Cable PN: 1392-50
  • Nominal Width: 1/4 in.
  • Nominal Thickness: 0.030 in.
  • Conductor Size: 36 Tinned Copper Wire AWG
  • Number of Ends: 168
  • Number of Carriers: 24
  • Total Strands: 168 x 36
  • Approx. Conductor Size: 14 AWG
  • CMA: 4200
  • Ampacity: 30 A
  • Approvals: ASTM B-33, QQ-W-343 Type S, RoHS

Overview

A tight weave of multi-strand, soft drawn tinned copper wire is an ideal shielding material for short-run cables providing easy radial termination. In retrofit applications, it provides additional shielding efficiency. Tinned copper flat braid can be used as a ground strap because it provides an excellent, low resistance ground path.

  • Also available in 100' spools.

    Applications

    • Shielding
    • Flexible Ground Straps

    Related Products

    • Dimensions & Appearance

    Style:Flat
    Color:Silver
    Length:50 ft.

    Features

    Conductor Strand:24 x 7 x 36
    Wire Gauge (AWG):14
    Inner Diameter:0.250 in.
    Outer Diameter:0.280 in.
    Current Rating:30 A
    ,
