133 mm x 126 mm x 33 mm Blower Fan 48 VDC Ball Bearing 27CFM 41.8dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$25.950

In Stock: 0

Quantity	Unit Price	You Save	Discount
500+	$25.950	-	-
1000+	$24.650	1.30	5.01%

Features

Voltage Rating: 48 VDC
Height: 126 mm
Width: 133 mm
Depth: 33 mm
Air Flow (CFM): 27
Bearing: Ball
Current Rating: 120 mA
Power Rating: 5.76 W
Agency Approvals: UL, CUL
Noise (dBA): 41.8
Termination: 12" Wires
Product Type: 126 mm x 133 mm Blower Fan
Speed: 2175 rpm
Maximum Pressure: 0.42 in.
Motor Drive Type: Brushless DC, Locked Rotor, Polarity Protected, Auto Restart

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the blower fan is designed to operate up to 2175 rpm.
