12W Regulated Dual Output DC-DC Converter


Output: ±5 Volts @ ±1.2 Amps

Features:
  • Input voltage range: 18-36VDC
  • Built-in EMI filter
  • Built-in remote on/off control
  • Cooling by free air convection
  • 100% full load burn-in test
  • 1500VDC I/O isolation
  • Protections: Short-circuit, overload
  • Five-sided shielded metal case
  • Efficiency: 80%
  • Compact size: 1.25"L x 0.8"W x 0.48"H
  • Weight: 0.65 oz. (18.5 grams)
  • 2-year warranty

    • Product Identification

    Type:Step Down
    Manufacturer Series:DCW12
    Product Type:DC-DC Regulated Dual Output SMPS

    Dimensions & Appearance

    Height:0.50 in.
    Width:0.80 in.
    Length:1.30 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:71°C

    Input

    Input Voltage:24 VDC
    Input Voltage Range:18 VDC to 36 VDC
    Maximum Input Current:0.625 A

    Output

    Number of Outputs:2
    Additional Output Voltages (VDC):-5 VDC
    Output Connector Type:DIP-24
    Output Voltage:5 VDC
    Output Current:1.20 A

    Features

    Pins:9
    Power Rating:12 W
    ,
