12W Regulated Dual Output DC-DC Converter


Output: ±12 Volts @ ±0.5 Amps

Features:
  • Input voltage range: 9-18VDC
  • Built-in remote on-off control
  • Built-in EMI filter
  • Cooling by free air convection
  • 100% full load burn-in test
  • 1500VDC I/O isolation
  • Five-sided shielded metal case
  • Protections: Short-circuit, overload
  • Efficiency: 84%
  • Compact size: 1.25"L x 0.8"W x 0.48"H
  • Weight: 0.65 oz. (18.5 grams)
  • 2-year warranty

    • Product Identification

    Type:Non-Inverting, Step Up, Step Down
    Product Type:DC-DC Regulated Dual Output SMPS
    Manufacturer Series:DCW12

    Dimensions & Appearance

    Height:0.50 in.
    Width:0.80 in.
    Length:1.30 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:71°C

    Input

    Input Voltage Range:9 VDC to 18 VDC
    Input Voltage:12 VDC
    Maximum Input Current:1.245 A

    Output

    Number of Outputs:2
    Output Connector Type:DIP-24
    Additional Output Voltages (VDC):-12 VDC
    Output Voltage:12 VDC
    Output Current:0.50 A

    Features

    Pins:9
    Power Rating:12 W
    ,
