12W Encapsulated Dual Output DC-to-DC Converter

Output: ±12 Volts @ 0.5 Amps

Features:

  • Input range: 18-36VDC
  • Number of pins: 9
  • Line Regulation: ±0.5%
  • Load Regulation: ±0.5%
  • Ripple and Noise: 60mVp-p
  • Short-circuit/overload protection
  • 1000VDC I/O isolation
  • Shield metal case
  • Cooling by free air convection
  • Size: 1.25"L x 0.8"W x 0.48"H

    • Product Identification

    Type:Step Down
    Manufacturer Series:DCW12
    Product Type:DC-DC Regulated Dual Output SMPS

    Dimensions & Appearance

    Height:0.50 in.
    Width:0.80 in.
    Length:1.30 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:71°C

    Input

    Input Voltage:24 VDC
    Input Voltage Range:18 VDC to 36 VDC
    Maximum Input Current:0.625 A

    Output

    Number of Outputs:2
    Output Connector Type:DIP-24
    Additional Output Voltages (VDC):-12 VDC
    Output Voltage:12 VDC
    Output Current:0.50 A

    Features

    Pins:9
    Power Rating:12 W
    ,
