DC to DC Regulated Single Output 50 Watt Converter 12 Volts 0.41 to 4.17 Amps 50 Watts
12 Volts @ 0.41 to 4.17 AmpsSpecifications
- Output Power (W): 50
- Voltage Range (VDC): 18 to 36
- Under Voltage Shutdown (VDC): 16
- Ripple & Noise (mV p-p): 80
- Line Regulation (±): 0.2%
- Load Regulation (±): 0.5%
- Voltage Accuracy (±): 2.0%
- Efficiency: 92%
- Size (inches):2 by 1
- Wide Input Range: 2 : 1"
- 1500 VDC I/O Isolation""
- Built in Remote On/OFF Control""
- Short Circuit, Overload, Input and Output Over Voltage Protection""
- Cooling by Free Air Convection""
- 100% Burn in Test"
- Agency Approvals: FCC/CE
- Waranty: 2 Years
Product Identification
Product Type:DC-DC Regulated Single Output SMPS
Manufacturer Series:SKM50
Dimensions & Appearance
Height:0.54 in.
Width:1 in.
Length:2 in.
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:75°C
Input
Input Voltage:24 VDC
Input Voltage Range:18 VDC to 36 VDC
Maximum Input Current:2.3 A
Output
Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:PC Pins
Additional Output Voltages (VDC):N/A
Output Current:4.17 A
Features
Pins:6
Efficiency:92%
Power Rating:50 W
