12V 83mA 1W Regulated Encapsulated DC-DC Converter 18-36V Input

12 Volts DC @ 8-83 mA

Specifications

  • Input voltage range: 18 to 36 V
  • Output current range: 8 mA to 83 mA
  • Size: 0.69" x 0.3" x 0.44"
  • Pins: 4
  • SIP package
  • 2:1 wide input range
  • Line regulation: ±0.5
  • Load regulation: ±0.5%
  • Ripple & noise: 80 mVp-p
  • 1500 VDC I/O isolation
  • Built-in EMI filter without external components
  • Cooling by free air convection
  • Protections: Short circuit, overload
  • 100% burn-in test
  • Low cost / high reliability
  • 2 year warranty

Product Identification

Product Type:DC-DC Regulated Single Output Converter SMPS
Manufacturer Series:SPA01

Dimensions & Appearance

Height:0.44 in.
Width:0.30 in.
Length:0.69 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C

Input

Maximum Input Current:0.055 A
Input Voltage:24 VDC
Input Voltage Range:18 VDC to 36 VDC

Output

Number of Outputs:1
Output Current:0.083 A
Output Voltage:12 VDC
Output Connector Type:PC Pins
Additional Output Voltages (VDC):N/A

Features

Pins:4
Power Rating:1 W
Efficiency:78%
,
