12V 5A 60W Reliable Railway Enclosed DC-DC Converter 9-36 Vin
Product Identification
Product Type:Isolated Railway DC to DC Converter SMPS
Manufacturer Series:RSD-60
Compliance
Agency Approvals:UL, CUL, CB, CE, EN, EAC
Dimensions & Appearance
Color:Silver
Height:0.98 in.
Width:2.36 in.
Length:5.04 in.
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:55°C
Packaging
Package:Railway Enclosed
Input
Input Voltage Range:9 VDC to 36 VDC
Input Voltage:24 VDC
Maximum Input Current:3 A
Output
Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Additional Output Voltages (VDC):N/A
Output Current:5 A
Features
Pins:4
Efficiency:92%
Power Rating:60 W
