12V 5A 60W Constant Current LED Driver

12 Volts DC @ 5 Amps

Specifications

  • Constant current mode output
  • Constant current region: 7.2 - 12 Volts
  • Rated power: 60 watts
  • Input voltage range: 200-400 VAC; 282-565VDC
  • Efficiency: 86%
  • Plastic housing with Class II design
  • Built-in active PFC function
  • IP67 rating for indoor and outdoor installations
  • Class 2 power unit
  • Function: 3 in 1 dimming
  • Typical lifetime: >50,000 hours
  • 5 year warranty

Applications

  • LED panel lighting
  • LED flood lighting
  • Indoor LED lighting
  • High bay lighting
  • Type "HL" for use in Class I, Division 2 hazardous (Classified) location

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:LPFH-60D

Compliance

Agency Approvals:UL, CUL, FCC, EN, EAC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:1.26 in.
Width:1.69 in.
Length:6.4 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C

Input

Input Frequency:47 Hz to 63 Hz
Maximum Input Current:0.4 A
Input Voltage:200 VAC to 400 VAC

Output

Number of Outputs:1
Output Range:7.2 VDC to 12 VDC
Output Voltage:12 VDC
Output Connector Type:Stripped and Tinned
Output Current:5 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3000V
IP Rating:IP67
Efficiency:86%
Power Rating:60 W
,
