128 mm x 120 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 235.5CFM 60.4dBA 12" Wires

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$39.950

In Stock: 0

Quantity	Unit Price	You Save	Discount
2+	$39.950	-	-
10+	$37.550	2.40	6.01%
50+	$35.250	4.70	11.76%

Features

Voltage Rating: 48 VDC
Height: 120 mm
Width: 128 mm
Depth: 38 mm
Air Flow (CFM): 235.5
Bearing: Ball
Current Rating: 900 mA
Power Rating: 43.2 W
Agency Approvals: UL, CUL, TUV, CE, UKCA
Noise (dBA): 60.4
Termination: 12" Wires
Product Type: 120mm x 120mm DC Fan
Speed: 4925 rpm
Maximum Pressure: 1.6 in.
Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 4925 rpm.
