127 mm x 127 mm x 38.5 mm Tube Axial Fan 48 VDC Ball Bearing 86CFM 30dBA 12" Wires

Features

  • Voltage Rating: 48 VDC
  • Height: 127 mm
  • Width: 127 mm
  • Depth: 38.5 mm
  • Air Flow (CFM): 86
  • Bearing: Ball
  • Current Rating: 70 mA
  • Power Rating: 3.36 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 30
  • Termination: 12" Wires
  • Product Type: 127mm x 127mm DC Fan
  • Speed: 1900 rpm
  • Maximum Pressure: 0.23 in.
  • Additional Features: PBT Frame, PBT Impeller
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 1900 rpm.

,
