125mm x 126mm x 39mm Blower Fan 115 VAC Dual Ball Bearing 30CFM 48dBA 12" Wires
Features
- Voltage Rating: 115 VAC
- Height: 126mm
- Width: 125mm
- Depth: 39mm
- Air Flow (CFM): 30
- Bearing: Dual Ball
- Current Rating: 157 mA
- Power Rating: 18 W
- Agency Approvals: UL, CUL, TUV, CE
- Noise (dBA): 48
- Termination: 12" Wires
- Product Type: 126mm x 125mm Blower Fan
- Speed: 2800 rpm
- Maximum Pressure: 0.51 in.
- Additional Features: Aluminum Die Cast Shell, UL94V-0 Impeller
- Motor Drive Type: Shaded Pole, Inner Rotor, Single Phase, Impedance Protected
Overview
Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Dual Ball bearing system of the blower fan is designed to operate up to 2800 rpm.
Product Identification
Additional Feature:Aluminum Die Cast Shell, UL94V-0 Impeller
Product Type:AC Blower Fan
Compliance
Dimensions & Appearance
Depth:39mm
Width:125mm
Height:126mm
Features
Bearing:Dual Ball
Air Flow (CFM):30
Noise (dBA):48
Maximum Pressure:0.51 in.
Speed:2800 rpm
Motor Drive Type:Shaded Pole, Inner Rotor, Single Phase, Impedance Protected
Termination:12" Wires
Voltage Rating:115 VAC
Power Rating:18 W
Current Rating:157 mA
