122.4W 3.4A 36V Single Output AC/DC Switching Power Supply

Specifications

  • Output Power (W): 122.4
  • DC Voltage (V): 36
  • Rated Current (A): 3.4
  • Ripple & Noise (mV p-p): 200
  • Efficiency: 90%
  • Line Regulation (%): ±0.5
  • Load Regulation (%): ±0.5
  • Size (L x W x H) inches: 7.51 x 2.48 x 1.47
  • Built-in 3in 1 dimming function
  • Universal AC input/Full range (up to 305VAC)
  • Built in PFC function
  • Protections: short circuit, over voltage, overload, over temperature
  • Cooling by free air convention
  • 5 years warranty

    • Product Identification

    Product Type:Auto Switching SMPS
    Manufacturer Series:NPF-120D

    Compliance

    Agency Approvals:UL, CUL, CB, CE, EN, ENEC, EAC, CCC

    Dimensions & Appearance

    Style:Enclosed
    Color:Black
    Height:1.48 in.
    Width:2.48 in.
    Length:7.52 in.

    Operating conditions

    Minimum Operating Temperature:-40°C
    Maximum Operating Temperature:70°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Input Voltage:90 VAC to 305 VAC
    Maximum Input Current:1.3 A

    Output

    Number of Outputs:1
    Output Connector Type:Stripped and Tinned
    Output Voltage:36 VDC
    Output Range:N/A
    Output Current:3.40 A

    Features

    PFC Function:Yes
    Minimum Isolation Voltage:3750V
    IP Rating:IP67
    Efficiency:89.5%
    Power Rating:122.4 W
    ,
