120 mm x 120 mm x 25 mm Tube Axial Fan 115 VAC Dual Ball Bearing 80CFM 44dBA Terminals

Features

  • Voltage Rating: 115 VAC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 25 mm
  • Air Flow (CFM): 80
  • Bearing: Dual Ball
  • Current Rating: 180 mA
  • Power Rating: 16 W
  • Noise (dBA): 44
  • Termination: Terminals
  • Product Type: AC Fan
  • Speed: 2350 rpm
  • Maximum Pressure: 0.23 in.
  • Additional Features: Die Cast Aluminum Frame, Plastic Impeller
  • Motor Drive Type: AC Shaded Pole, Impedance Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Dual Ball bearing system of the tube axial fan is designed to operate up to 2350 rpm.

Product Identification

Product Type:AC Fan
Additional Feature:Die Cast Aluminum Frame, Plastic Impeller

Dimensions & Appearance

Depth:25 mm
Width:120 mm
Height:120 mm

Features

Bearing:Dual Ball
Maximum Pressure:0.23 in.
Motor Drive Type:AC Shaded Pole, Impedance Protected
Speed:2350 rpm
Noise (dBA):44
Voltage Rating:115 VAC
Air Flow (CFM):80
Termination:Terminals
Power Rating:16 W
Current Rating:180 mA
,
