120x120x25mm Brushless Fan 24 VDC 98 CFM Dual Ball Bearing

Specifications

  • Voltage: 24 Volts DC
  • Current rating: 300 mA
  • Power: 6 watts
  • Size: 120 x 120 x 25 (mm)
  • Air Flow: 98 CFM
  • Bearing: Dual ball bearing
  • Noise: 50.2 dBA
  • Connection: (4) 12" lead wires, PWM & FG
  • Agency approval: UL, CUL, TUV, CE

Product Identification

Product Type:DC Fan

Compliance

Agency Approvals: CE, CUL, TUV, UL

Dimensions & Appearance

Depth:25 mm
Width:120 mm
Height:120 mm

Features

Bearing:Dual Ball
Speed:3600 rpm
Voltage Rating:24 VDC
Noise (dBA):50.2
Termination:12" Wires (4), PWM + FG
Power Rating:6 W
Air Flow (CFM):98
Current Rating:300 mA
,
