120W DIN Rail Type DC-DC Converter 16.8-33.6VDC Input 12V 10A Output
Features
- Width only 32mm
- -40 to 70°C
- 2:1 wide input range
- DC output adjustable(±10%)
- 4000 VDC I/O isolation
- Can be installed on DIN rail TS-35/7.5 or 15
- Cooling by free air convection
- Protections: Short circuit/Overload/Over voltage/Input reverse polarity/Input under voltage protection
- No minimum load required
- 3 year warranty
Applications
- Telecom or Datacom system
- Factory automation
- Electro-mechanical
- Wireless network
- Semi-conductor fabrication equipment
- Industrial control system
Product Identification
Product Type:DC-DC Converter SMPS
Manufacturer Series:DDR-120
Compliance
Agency Approvals:CE
Dimensions & Appearance
Color:Carbon
Width:1.26 in.
Height:4.93 in.
Length:4.02 in.
Mounting:DIN Rail
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C
Input
Input Voltage:24 VDC
Input Voltage Range:16.8 VDC to 33.6 VDC
Maximum Input Current:5.6 A
Output
Number of Outputs:1
Output Voltage (Channel 1):12 VDC
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):10 A
Output Current:10 A
Features
Efficiency:89%
Power Rating:120 W
