120W Single Output Industrial DIN RAIL Power Supply
24 Volts @ 5 AmpsFeatures:
- Wide input range 180 ~ 550VAC
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Built-in constant current limiting circuit
- Can be installed on DIN rail TS-35/7.5 or 15
- UL508(industrial control equipment)approved
- EN61000-6-2(EN50082-2) industrial immunity level
- 100% full load burn-in test
- Built-in DC OK relay contact
- 3 year warranty
Product Identification
Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:WDR-120
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, UL
Dimensions & Appearance
Depth:1.57 in.
Color:Silver
Height:4.47 in.
Width:4.93 in.
Operating conditions
Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:180 VAC to 550 VAC
Maximum Input Current:1.2 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:5 A
Features
PFC Function:No
Low Power Source (LPS):No
Efficiency:91%
Power Rating:120 W
