120W 10A 12V PWM Output LED Power Supply

Specifications

  • Output Power (W): 120
  • DC Voltage (V): 12
  • Rated Current (A): 10
  • Size (L x W x H) inches: 7.51 x 2.48 x 1.47
  • Efficiency (%): 89
  • Universal AC input/Full range
  • Suitable for dry, damp, wet locations
  • Protections: short circuit, over voltage, overload, over temperature
  • 5 years warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:PWM-120

Compliance

Agency Approvals: CB, CCC, CE, CUL, EAC, EN, ENEC, UL

Dimensions & Appearance

Style:Enclosed
Color:Black
Height:1.48 in.
Width:2.48 in.
Length:7.52 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 305 VAC
Maximum Input Current:1.3 A

Output

Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Stripped and Tinned
Output Range:N/A
Output Current:10 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP67
Efficiency:88%
Power Rating:120 W
,
