120 mm x 120 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 124.1CFM 44dBA Terminals

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$29.150

In Stock: 0

Quantity	Unit Price	You Save	Discount
2+	$29.150	-	-
10+	$27.350	1.80	6.17%
50+	$25.650	3.50	12.01%

Features

Voltage Rating: 48 VDC
Height: 120 mm
Width: 120 mm
Depth: 38 mm
Air Flow (CFM): 124.1
Bearing: Ball
Current Rating: 500 mA
Power Rating: 24 W
Agency Approvals: UL, CUL, TUV
Noise (dBA): 44
Termination: Terminals
Product Type: 120mm x 120mm DC Fan
Speed: 2895 rpm
Maximum Pressure: 0.469 in.
Motor Drive Type: Brushless DC, Auto Restart, IC Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 2895 rpm.
