120 mm x 120 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 118CFM 43dBA Terminals

Features

  • Voltage Rating: 48 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 38 mm
  • Air Flow (CFM): 118
  • Bearing: Ball
  • Current Rating: 100 mA
  • Power Rating: 4.8 W
  • Agency Approvals: UL, CUL, TUV
  • Noise (dBA): 43
  • Termination: Terminals
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 3000 rpm
  • Maximum Pressure: 0.28 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3000 rpm.

,
