120 mm x 120 mm x 38 mm Tube Axial Fan 24 VDC Sealed Sleeve Bearing 96CFM 47dBA 12" Wires

Features

  • Voltage Rating: 24 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 38 mm
  • Air Flow (CFM): 96
  • Bearing: Sealed Sleeve
  • Current Rating: 230 mA
  • Power Rating: 5.52 W
  • Agency Approvals: UL, CUL, TUV
  • Noise (dBA): 47
  • Termination: 12" Wires
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 2540 rpm
  • Maximum Pressure: 0.23 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Sealed Sleeve bearing system of the tube axial fan is designed to operate up to 2540 rpm.

,
