120 mm x 120 mm x 38 mm Tube Axial Fan 24 VDC Ball Bearing 70CFM 25dBA Terminals

Features

  • Voltage Rating: 24 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 38 mm
  • Air Flow (CFM): 70
  • Bearing: Ball
  • Current Rating: 150 mA
  • Power Rating: 3.6 W
  • Agency Approvals: UL, CUL, TUV
  • Noise (dBA): 25
  • Termination: Terminals
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 1950 rpm
  • Maximum Pressure: 0.25 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 1950 rpm.

,
