120 mm x 120 mm x 38 mm Tube Axial Fan 24 VDC Ball Bearing 226CFM 65dBA 12" Wires (4)

Features

  • Voltage Rating: 24 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 38 mm
  • Air Flow (CFM): 226
  • Bearing: Ball
  • Current Rating: 2040 mA
  • Power Rating: 48.96 W
  • Agency Approvals: UL, CUL, TUV
  • Noise (dBA): 65
  • Termination: 12" Wires (4)
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 5000 rpm
  • Maximum Pressure: 1.35 in.
  • Additional Features: Open Collector Tach Output and PWM
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 5000 rpm.

,
