120 mm x 120 mm x 38 mm Tube Axial Fan 24 VDC Ball Bearing 124.1CFM 44.1dBA 12" Wires

Features

  • Voltage Rating: 24 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 38 mm
  • Air Flow (CFM): 124.1
  • Bearing: Ball
  • Current Rating: 500 mA
  • Power Rating: 12 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 44.1
  • Termination: 12" Wires
  • Speed: 2895 rpm

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The

  • Bearing: Ball bearing system of the tube axial fan is designed to operate up to
  • Bearing: 2895 rpm.

    • Product Identification

    Product Type:DC Fan

    Compliance

    RoHS Status:ROHS Compliant
    Compliance:Compliance Docs
    Agency Approvals: CE, CUL, TUV, UKCA, UL

    Dimensions & Appearance

    Depth:38 mm
    Width:120 mm
    Height:120 mm

    Features

    Bearing:Ball
    Air Flow (CFM):124.1
    Noise (dBA):44.1
    Speed:2895 rpm
    Voltage Rating:24 VDC
    Termination:12" Wires
    Power Rating:12 W
    Current Rating:500 mA
    ,
