120 mm x 120 mm x 32 mm Tube Axial Fan 24 VDC Ball Bearing 107CFM 40.1dBA 12" Wires (3)

Features

  • Voltage Rating: 24 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 32 mm
  • Air Flow (CFM): 107
  • Bearing: Ball
  • Current Rating: 350 mA
  • Power Rating: 8.4 W
  • Agency Approvals: UL, CUL, TUV, CE
  • Noise (dBA): 40.1
  • Termination: 12" Wires (3)
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 3250 rpm
  • Maximum Pressure: 0.46 in.
  • Additional Features: Open Collector Alarm Output
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3250 rpm.

,
