120 mm x 120 mm x 32 mm Tube Axial Fan 120 VAC Dual Ball Bearing 120CFM 47dBA AC-DC Wall Adapter

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$67.350

In Stock: 0

Quantity	Unit Price	You Save	Discount
1+	$67.350	-	-
5+	$61.950	5.40	8.02%
25+	$56.950	10.40	15.44%

Features

Voltage Rating: 120 VAC
Height: 120 mm
Width: 120 mm
Depth: 32 mm
Air Flow (CFM): 120
Bearing: Dual Ball
Current Rating: 600 mA
Power Rating: 19 W
Agency Approvals: UL, CSA, TUV, CE
Noise (dBA): 47
Termination: AC-DC Wall Adapter
Product Type: 120mm x 120mm AC Fan
Speed: 3750 rpm
Maximum Pressure: 0.43 in.
Additional Features: Thermally Controlled, Smart Cooling Fan, Kit with Fan/Fan Guard/Power Adapter
Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected, Thermal Control

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Dual Ball bearing system of the tube axial fan is designed to operate up to 3750 rpm.
