120 mm x 120 mm x 25 mm Tube Axial Fan 48 VDC Ball Bearing 70CFM 25dBA 12" Wires

Features

  • Voltage Rating: 48 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 25 mm
  • Air Flow (CFM): 70
  • Bearing: Ball
  • Current Rating: 60 mA
  • Power Rating: 2.88 W
  • Agency Approvals: UL, CUL, TUV, CE
  • Noise (dBA): 25
  • Termination: 12" Wires
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 1900 rpm
  • IP Rating: IP68
  • Maximum Pressure: 0.15 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 1900 rpm.

,
