120 mm x 120 mm x 25 mm Tube Axial Fan 24 VDC Ball Bearing 133.8CFM 55.2dBA 12" Wires

Features

  • Voltage Rating: 24 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 25 mm
  • Air Flow (CFM): 133.8
  • Bearing: Ball
  • Current Rating: 850 mA
  • Power Rating: 20.4 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 55.2
  • Termination: 12" Wires
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 4950 rpm
  • Maximum Pressure: 0.75 in.
  • Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 4950 rpm.

Product Identification

Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:25 mm
Width:120 mm
Height:120 mm

Features

Bearing:Ball
Motor Drive Type:Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected
Noise (dBA):55.2
Maximum Pressure:0.75 in.
Voltage Rating:24 VDC
Speed:4950 rpm
Termination:12" Wires
Air Flow (CFM):133.8
Power Rating:20.4 W
Current Rating:850 mA
,
