120 mm x 120 mm x 25 mm Tube Axial Fan 24 VDC Ball Bearing 120CFM 42dBA Terminals

Orion Fans

Jameco Part #:

Manufacturer #:

Primary datasheet

Product Price:

$22.650

In Stock: 0

Quantity	Unit Price	You Save	Discount
3+	$22.650	-	-
12+	$21.250	1.40	6.18%
48+	$19.950	2.70	11.92%

Features

Voltage Rating: 24 VDC
Height: 120 mm
Width: 120 mm
Depth: 25 mm
Air Flow (CFM): 120
Bearing: Ball
Current Rating: 230 mA
Power Rating: 5.52 W
Agency Approvals: UL, CUL, TUV, CE
Noise (dBA): 42
Termination: Terminals
Product Type: 120mm x 120mm DC Fan
Speed: 3100 rpm
Maximum Pressure: 0.24 in.
Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3100 rpm.
