120 mm x 120 mm x 25 mm Tube Axial Fan 24 VDC Ball Bearing 120CFM 42dBA 12" Wires

Features

  • Voltage Rating: 24 VDC
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 25 mm
  • Air Flow (CFM): 120
  • Bearing: Ball
  • Current Rating: 230 mA
  • Power Rating: 5.52 W
  • Agency Approvals: UL, CUL, TUV, CE
  • Noise (dBA): 42
  • Termination: 12" Wires
  • Product Type: 120mm x 120mm DC Fan
  • Speed: 3100 rpm
  • IP Rating: IP68
  • Maximum Pressure: 0.24 in.
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3100 rpm.

Product Identification

Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UL

Dimensions & Appearance

Depth:25 mm
Width:120 mm
Height:120 mm

Features

Bearing:Ball
Noise (dBA):42
Air Flow (CFM):120
Maximum Pressure:0.24 in.
Motor Drive Type:Brushless DC, Auto Restart, Polarity Protected, Electronically Protected
IP Rating:IP68
Speed:3100 rpm
Voltage Rating:24 VDC
Termination:12" Wires
Power Rating:5.52 W
Current Rating:230 mA
,
