12VDC Reversible Plastic Gear Head Motor

GH35GM Series

Features:

  • Rated voltage: 12VDC
  • Operating range: 4.5 to 12VDC
  • Current @ maximum efficiency: 0.22A
  • Speed @ maximum efficiency: 4.5 RPM
  • Torque @ maximum efficiency: 4500 g-cm
  • Gear ratio: 1000:1
  • Gear case size: 1.3" diameter x 0.9" length
  • Motor size: 1.5" diameter x 1.0" length
  • Shaft size: 0.23" diameter x 0.9" length
  • Solder-type terminals
  • Dielectric strength: 300VDC
  • Insulation resistance: 10MΩ
  • Oil bearing design for long service life
  • Screw Mount Dimensions: M3

    • Product Identification

    Additional Feature:Plastic Gears

    Dimensions & Appearance

    Shaft Diameter:0.23 in.
    Shaft Length:0.9 in.
    Shaft Style:D

    Input

    Input Voltage Range:4.5 VDC to 12 VDC

    Features

    Motor Speed @ Max. Efficiency (RPM):4.5
    Current @ Max. Efficiency (mA):220
    Gear Case Size (Diameter x Length) (inch):1.40 x 0.90
    Gear Ratio:1000:1
    Terminal Type:Solder Tabs
    Voltage Rating:12 VDC
    Torque @ Max. Efficiency (g-cm):4500
    Motor Size (Diameter x Length) (inch):1.3 x 1.0
    ,
