120 Watt Single Output Lead-Acid Battery Charger

Output: 27.6 Volts @ 4.3 Amps

Features:
  • Input voltage: 88-132VAC / 176-264VAC @ 47-63Hz, selectable by switch
  • 3 poles AC inlet with fuse holder
  • Charger type can be selected (optional)
  • Built-in passive PFC function
  • AC on-off switch
  • 2 color LED loading indicator
  • Protections: Short-circuit, overload, over-voltage, over-temperature
  • Efficiency: 79%
  • Open PCB without case
  • Size: 5.67"L x 3.54"W x 1.30"H
  • Weight: 2.4 lbs.
  • 2-year warranty

    • Product Identification

    Product Type:Battery Charger
    Additional Feature:Single Output Power Supply or Battery Charger, Voltage Detector
    Manufacturer Series:PA-120

    Compliance

    Agency Approvals: CB, CE, CUL, EN, TUV, UL

    Dimensions & Appearance

    Color:Black
    Height:1.93 in.
    Width:3.78 in.
    Length:7.09 in.

    Operating conditions

    Minimum Operating Temperature:-10°C
    Maximum Operating Temperature:45°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Input Voltage:90 VAC to 132 VAC, 180 VAC to 264 VAC
    Maximum Input Current:3 A

    Output

    Output Connector Type:JST B3P-VH or equivalent
    Output Voltage:27.6 VDC
    Output Current:4.30 A

    Features

    PFC Function:Yes
    AC Power Cord:NOT INCLUDED, RECOMMEND 2271575
    Efficiency:79%
    Power Rating:118.68 W
    ,
