11.6W DIN Rail Type DC-DC Converter 18-75VDC Input 3.3V 3.5A Output

Features

  • Width only 17.5mm (1SU)
  • -40 to 85°C
  • 4:1 wide input range
  • DC output adjustable(±10%)
  • 4000 VDC I/O isolation
  • Can be installed on DIN rail TS-35/7.5 or 15
  • Cooling by free air convection
  • Protections: Short circuit/Overload/Over voltage/Input reverse polarity/Input under voltage protection
  • No minimum load required
  • 3 year warranty

Applications

  • Telecom or Datacom system
  • Factory automation
  • Electro-mechanical
  • Wireless network
  • Semi-conductor fabrication equipment
  • Industrial control system

    • Product Identification

    Product Type:DC-DC Converter SMPS
    Manufacturer Series:DDR-15

    Compliance

    Agency Approvals:CE

    Dimensions & Appearance

    Color:Carbon
    Width:0.688 in.
    Height:2.30 in.
    Length:3.54 in.
    Mounting:DIN Rail

    Operating conditions

    Minimum Operating Temperature:-40°C
    Maximum Operating Temperature:85°C

    Input

    Input Voltage Range:18 VDC to 75 VDC
    Input Voltage:48 VDC
    Maximum Input Current:3.6 A

    Output

    Number of Outputs:1
    Output Voltage (Channel 1):3.3 VDC
    Output Current (Channel 1):0.63 A
    Output Voltage:3.3 VDC
    Output Connector Type:Screw Terminal Block
    Output Current:4.50 A

    Features

    Minimum Isolation Voltage:400VDC
    Switching Regulator:None
    Pins:4
    Efficiency:84%
    Power Rating:15 W
    ,
