114 to 229 Volt 1.4A 320 Watt Enclosed Switching Constant Current Mode LED Power Supply

1.4A @ 114 to 229

Features

  • "B" model - 3 In 1 Dim Function
  • IP67 design for indoor or outdoor installations
  • Constant current mode output
  • Metal housing with Class I design
  • Built-in active PFC function
  • Typical life: >62,000 hours
  • Input voltage: 90-305 VAC @ 47-63 Hz
  • Efficiency: 94 %
  • Size: 9.9"L x 3.54"W x 1.72"H
  • Case color: Silver
  • Agency approvals: UL, CB, CE
  • 7 year warranty

Applications

      Overview

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:HLG-320H-C

Compliance

Agency Approvals:UL, CUL, CB, CE, EN, ENEC, EAC, CCC

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.72 in.
Width:3.54 in.
Length:9.92 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 305 VAC
Maximum Input Current:3.5 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Voltage:See Output Range
Output Current:1.40 A
Output Range:114 VDC to 229 VDC

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP67
Efficiency:94%
Power Rating:320.6 W
,
