Features
- DoE Level VI & CoC V5 Tier 2
- LPS compliant
- Field Changeable AC Plugs
- IP21 rating
- 2XMOPP Isolation
- Class II
- Suitable for BF applications with system consideration
- OVP, OCP, SCP, OTP, brown-in and brown-out protections
Overview
Applications
- Home healthcare equipment
- Patient monitor
- Portable medical devices
- ECG machine
- Respirator
Product Identification
Product Type:Switching SMPS Green Adapter
Manufacturer Series:PMA10
Compliance
Agency Approvals:UL, CSA
Dimensions & Appearance
Color:Black
Style:Interchanceable AC Clip
Height:1.57 in.
Width:1.96 in.
Length:2.82 in.
Operating conditions
Minimum Operating Temperature:5°C
Maximum Operating Temperature:40°C
Input
Input Frequency:47 Hz to 63 Hz
Input Connector:Interchangeable
Maximum Input Current:0.3 A
Input Voltage:90 VAC to 264 VAC
Output
Number of Outputs:1
Output Cord Length:1.5 m
Output Connector Diameters:2.1mm x 5.5mm
Output Voltage:5 VDC
Output Connector Type:Cylindrical Female
Output Current:2 A
Features
Polarity:Center Positive
Product Note:Level VI
AC Power Cord:N/A
Efficiency:N/A
Power Rating:10 W
