100.8W DC/DC CONVERTER
24 Volts @ 4.2 Amps
Specifications:
- Input Range: 36-72VDC
- Size (L x W x H) (inches): 7.8 x 3.9 x 1.5
- Number of pins: 7
- Ripple and Noise (mV p-p): 150
- Load Regulation: 0.2%
- Line Regulation: 0.2%
- Built-in EMI filter, low ripple noise
- 2-year warranty
- Certifications: CE
Product Identification
Type:Step Down
Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-100
Compliance
Agency Approvals: EAC, EN, CE, CE, EN, EAC
Dimensions & Appearance
Mounting:Enclosed
Height:1.5 in.
Width:3.9 in.
Length:7.8 in.
Operating conditions
Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C
Packaging
Package:Enclosed
Input
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC
Maximum Input Current:2.4 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:4.20 A
Features
Switching Regulator:Yes
Pins:7
Efficiency:81%
Power Rating:100.8 W
