100.8W 1400mA Single Output LED Power Supply

Specifications

  • Output Power (W): 100.8
  • Ripple & Noise (V p-p): 1
  • Efficiency: 89.5%
  • Rated Current(mA): 1400
  • Size (L x W x H) inches: 7.48 x 2.04 x 1.45
  • Universal AC input / Full range
  • Protections: short circuit, over voltage
  • Fully isolated plastic case
  • 2 year warranty

    • Product Identification

    Product Type:Auto Switching SMPS
    Manufacturer Series:LPC-100

    Compliance

    Agency Approvals:EN, EAC, CE

    Dimensions & Appearance

    Style:Enclosed
    Color:White
    Height:1.46 in.
    Width:2.05 in.
    Length:7.48 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:50°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Input Voltage:90 VAC to 264 VAC
    Maximum Input Current:2.2 A

    Output

    Number of Outputs:1
    Output Connector Type:Stripped and Tinned
    Output Voltage:See Output Range
    Output Range:36 VDC to 72 VDC
    Output Current:1.40 A

    Features

    PFC Function:No
    Minimum Isolation Voltage:3000V
    IP Rating:IP67
    Efficiency:89.5%
    Power Rating:100.8 W
    ,
